HIWIN RGW35HC CNC Linear Rail Set Linear Motion Rails 35mm Size

Name: HIWIN RGW35HC CNC Linear Rail Set Linear Motion Rails 35mm Size
Brand: Nanjing Tibi Ai Import and Export Trading Co., Ltd.
SKU: RGW35HC
Price: 50.00 USD
Availability: InStock

Brand Name:	HIWIN
Model Number:	RGW35HC
MOQ:	10
Price:	1-100 USD
Delivery Time:	1-7 work days
Payment Terms:	T/T,L/C,D/A,D/P,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA TAIWAN

Certification:

DE1924083895474

Series:

Model Size(mm):

35mm

No. Of Blocks Per Rail:

Rail Mounting Type:

R- Mounting From Top

Rail Length(mm):

Max 4000mm

Preload Class:

Z0- Light Preload , ZA- Medium Preload, ZB-Heavy Preload

Material:

SNCM220 Carbon Steel

Dust Protection:

SS-standard

Y -Symmetrical (E1＝E2) First Hole Dimension:

Y= Symmetrical （E1=E2)

Installation:

Easy

Application:

Automation Systems, Transportation Equipment, CNC Machining Centers, Heavy Duty Cutting Machines

Smoothness:

Smooth

Packaging Details:

Small or with carton box, Bulk order with Wooden box

Supply Ability:

100000 pcs / per month

Highlight:

RGW35HC Linear Rail Set

RGW35HC Linear Motion Rails

CNC Linear Rail Set

Product Description

①HIWIN RGW35HC Linear Guideway CNC Slider Linear Way Linear Rail Set

The HIWIN RGW35HC Linear Guideway System represents a cutting-edge motion solution engineered to meet the rigorous demands of modern automated manufacturing environments. Designed for seamless integration into high-performance CNC systems and industrial automation platforms, this precision rail set delivers the exceptional stability and repeatability required for unmanned production lines and smart factory applications. The system's advanced roller technology ensures buttery-smooth motion characteristics, enabling precise positioning in robotic welding cells, automated assembly stations, and high-speed material handling systems where consistent performance is critical. Its robust construction withstands the dynamic loads and continuous operation typical of 24/7 manufacturing while maintaining micron-level accuracy across millions of cycles. The RGW35HC's contamination-resistant design features specialized seals that protect critical components from industrial debris without compromising movement fluidity - a key advantage for automated systems operating in challenging environments. The guideway's vibration-damping properties and thermal-stable construction ensure reliable performance in precision applications like laser processing, automated inspection, and electronic component manufacturing. Compatible with advanced feedback systems and IoT-enabled monitoring, this linear motion solution supports the data-driven precision required by Industry 4.0 automation strategies. Whether deployed in automotive production lines, packaging machinery, or semiconductor manufacturing equipment, the HIWIN RGW35HC provides the dependable motion control foundation that allows automated systems to achieve peak productivity while minimizing maintenance requirements. By combining industrial-grade durability with refined motion characteristics, this complete rail set exemplifies HIWIN's commitment to delivering automation solutions that push the boundaries of precision, reliability, and smart manufacturing capabilities.

②Drawing of RGW35HC

③Model Number of RG Series

④Construction of RG Series

1.Rolling circulation system: Block, rail, end cap, Circulation path, rollers

2.Lubrication system: Grease nipple and piping joint

3.Dust protection system: End seal, bottom seal,bolt cap, double seals and scraper.


⑤Features of RG series
The new RG series from HIWIN features a roller as the rolling element instead of steel balls. The roller series offers super high rigidity and very high load capacities. The RG series is designed with a 45-degree angle of contact. Elastic deformation of the linear contact surface, during load, is greatly reduced thereby offering greater rigidity and higher load capacities in all 4 load directions.The RG series linear guideway offers high performance for high-precisionmanufacturing and achieving longer service life.
1. Optimal design
FEM analysis was performed to determine the optimal structure of the block and the rail. The unique design of the circulation path allows the RG series linear guideway to offer smoother linear motion.
2.Super high rigidity
The RG series is a type of linear guideway that uses rollers as the rolling elements. Rollers have a greater contact area thanballs so that the roller guideway features higher load capacityand greater rigidity. The figure shows the rigidity of a roller and a ball with equal volume.
3. Super high load capacity
With the four rows of rollers arranged at a contact angle of 45-degrees, the RG series linear guideway has equal load ratings in the radial, reverse radial and lateral directions.The RG series has a higher load capacity in a smaller size than conventional, ball-type linear guideways.
4. Operating life increased
Compare with the ball element, the contact pressure of rolling element is distributed on the line region. Therefore,stress concentration was reduced siginificantly and the RG series offers longer running life. The nominal life of RG seriescan be calculated by using Eq.

⑥Actual product photo

HIWIN RGW35HC CNC Linear Rail Set Linear Motion Rails 35mm Size 3

⑦Measurement drawing

⑧HIWIN series

⑨top product recommendation
