HIWIN Linear Guide
Created with Pixso. WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails

Brand Name: HIWIN
Model Number: WEH21CA
MOQ: 10
Price: 1-100 USD
Delivery Time: 1-7 work days
Payment Terms: T/T,L/C,D/A,D/P,Western Union
Detail Information
Place of Origin:
CHINA TAIWAN
Certification:
DE1924083895474
Series:
WE
Model Size(mm):
21mm
No. Of Blocks Per Rail:
1
Rail Mounting Type:
R- Mounting From Top
Rail Length(mm):
Max 4000mm
Preload Class:
Z0-Very Light Preload , ZA-Light Preload , ZB-Medium Preload
Material:
SNCM220 Carbon Steel
Dust Protection:
SS-standard
Y -Symmetrical (E1=E2) First Hole Dimension:
Y= Symmetrical (E1=E2)
Installation:
Easy
Application:
Automation Devices, Blow Moulding Machines, Precision Measuring Equipment
Smoothness:
Smooth
Packaging Details:
Small or with carton box, Bulk order with Wooden box
Supply Ability:
100000 pcs / per month
Highlight:

WEH21CA HIWIN Linear Guide

,

WEH21CA hiwin linear rails

,

Adjustable HIWIN Linear Guide

Product Description
①HIWIN WEH21CA Linear Guideway 21mm Adjustable Conveyor Guide Rails

      The HIWIN WEH21CA Linear Guideway is a game-changer in the realm of automation. It features a 21mm width, making it a versatile choice for various automated systems. In industrial automation setups, it serves as a reliable foundation for adjustable conveyor guide rails. This allows for seamless transportation of goods along production lines, ensuring each item moves precisely where it needs to go. For instance, in electronics assembly, it helps route circuit boards smoothly through different stages of production, from component installation to final testing. In automotive manufacturing, it enables the smooth conveyance of car parts, enhancing the overall efficiency of the assembly process. Its adaptability and precision make it an essential tool for any automated operation looking to optimize productivity and streamline workflows.

②Drawing of WEH21CA
WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 0
③Model Number of WE Series

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 1
④Construction of WE Series
WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 2
1.Rolling circulation system: Block, rail, end cap and retainer
2.Lubrication system: Grease nipple and piping joint
3.Dust protection system: End seal, bottom seal, cap and scraper.

⑤Features of WE series
The WE series features equal load ratings in the radial, reverse radial and the lateral direction with contact points at 45degrees. This along with the wide rail, allows the guide way to be rated for high loads, moments and rigidity. By design, it has a self-aligning capacity that can absorb most installation errors and can meet high accuracy standards.The ability to use a single rail and to have the low profile with a low center of gravity is ideal where space is limited and/or high moments are required.


Actual product photo

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 3


Measurement drawing
WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 4

WEH21CA HIWIN Linear Guide 21mm Width Adjustable Conveyor Guide Rails 5
