440C Hardened Ø25×562 Linear Shaft for SBR25UU Controlled G6 Fit, Surface Finish, and Straightness We supplied a custom linear motion shaft for a U.S. customer building machine-grade food equipment. The shaft was specified in 440C stainless steel with a required hardness of HRC 52–54, and designed to run with a SBR25UU bearing block. No aluminum support rail was used. The customer emphasized that material and hardness were critical and required strict adherence to the technical drawing. To manage common risks in custom hardened shafts—such as heat-treatment distortion, diameter drift, and surface variation—we followed an inspection-driven workflow aligned to critical-to-quality requirements. This case study was prepared with AI assistance and reviewed internally. All requirements are based on customer specifications and verified through project-level inspection. Project Snapshot Component: Linear motion shaft with custom end machining Size: Ø25 mm × 562 mm Material: 440C stainless steel Hardness requirement: HRC 52–54 Mating bearing: SBR25UU (no support rail) Application: Machine-grade food equipment This summary makes the key technical elements explicit. It allows engineers and buyers to quickly confirm whether this case matches their application, and anchors the discussion to measurable technical requirements rather than general capability claims. Customer Requirements (Critical-to-Quality) The customer stated that hardness and material selection were non-negotiable. In practical terms, this makes hardness, diameter control, surface finish, and straightness stop-ship items. A shaft can appear acceptable but still cause operational issues when paired with a bearing block. Because the shaft operates without a support rail, alignment sensitivity increases. Local deviations in size or straightness can lead to stick-slip motion, noise, or uneven load distribution. Item Requirement Engineering Purpose Material 440C stainless steel Provides high hardness potential and wear resistance after heat treatment Hardness HRC 52–54 Supports stable rolling contact and surface durability Diameter tolerance G6 (–0.007 / –0.020 mm) Balances smooth motion and fit stability with SBR25UU Surface finish Ra ≤ 12 µin Reduces friction and vibration during operation Straightness ≤ 0.03 mm / 300 mm Prevents tight spots and uneven bearing load Part Features and Machining Scope Stepped shoulders Threaded sections Keyway Mounting holes These features increase manufacturing complexity in hardened shafts. Heat treatment can introduce distortion, and poor edge control may affect installation. Even when the main working diameter meets tolerance, transitions and edges still require careful control to protect the bearing block. For food-equipment applications, burrs and trapped chips are treated as quality risks, not cosmetic issues. Cleaning and edge control are therefore integrated into the process. Quality and Production Experience In hardened 440C shafts, most issues are subtle and appear during motion rather than visual inspection. Common examples include local diameter variation, uneven surface finish, or straightness deviation over functional lengths. Our inspection approach reflects how the bearing interacts with the shaft. Diameter is checked at multiple positions and orientations, surface finish is controlled in the working zone, and straightness is evaluated according to drawing requirements. Plan for heat-treatment movement before final sizing Verify diameter stability along the working length Confirm surface finish where rolling contact occurs Deburr and clean all functional transitions Verification and Documentation For custom shafts, verification is based on critical-to-quality items rather than general capability. Inspection and material documentation are prepared per project and aligned with customer requirements. This allows engineering, quality, and procurement teams to review compliance efficiently. Hardness verification Diameter and fit checks Surface finish control Straightness evaluation Food-Equipment Handling and Compliance Boundary The scope of this project focused on material selection, hardness, and dimensional performance for food-equipment use. Full regulatory compliance depends on the complete machine design, operating environment, and customer validation process. We manufacture shafts to the approved drawing and support clean delivery practices including deburring, cleaning, drying, and protective packaging. Typical Deliverables Project-level inspection records Material certificate for 440C stainless steel Protective packaging for transport Optional handling or installation notes Clear deliverables reduce ambiguity and support internal approval processes before installation and commissioning. Need Engineering Support for Your Linear Motion Project? Share your drawing, application details, or technical questions. Our engineering team will review your requirements and provide clear feedback before quotation. Contact Our Engineering Team Typical response within one business day
